CNBM 275W Solar Panel is a polycrystalline solar module, the 275 watt solar panel is a great choice for homeowners who want to install a solar panel system.
This 275w solar panel from CNBM Solar has a cell efficiency of 18.7%, is a polycrystalline cell solar panel, and has many other features that make it an A-Grade product. It has MC4 connectors, which makes it compatible with other solar panels in the market. The best features of this product include the performance, features, reliability, and price of the cnbm 275 watt solar panel. CNBM 275W polycrystalline silicon solar panel is the best solution for household and commercial use. CNBM solar panels are the epitome of quality and efficiency.
We sell 275W Poly Crystalline CNBM6P-275 panels that can be installed onto any roof, which makes them especially effective for homeowners looking for a simple way to convert the sun’s energy into electricity. 275 watt solar panels prices helps provide a steady flow of power to your home, since the sun has been plentiful and reliable. CNBM 6P-275 275W Poly Solar Panel will improve your home or business by providing reliable solar power.
So if you’re looking for an affordable way to get started with solar energy, look no further than the CNBM 275W Solar Panel!
DATASHEET.
Model: CNBM 6P-275 275W.
Brand: CNBM Solar.
ELECTRICAL PARAMETERS.
- Rated Maximum Power (Mp): 275W.
- Power Tolerance: 0 – +_5W.
- Cell Efficiency: 18.7%.
- Open Circuit Voltage (Voc): 38.6V.
- Maximum Power Voltage (Vmp): 31.3V.
- Short Circuit Current (Isc): 9.31A.
- Maximum Power Current (Imp): 8.79A.
MATERIALS AND MECHANICAL PARAMETERS.
- Type of Cells: Poly-crystalline, 156.75 X 156.75mm.
- Cell Arrangement: 6 x 10 = 60.
Dimensions: 1640 x 992 x 40 mm. - Weight: 18.0kg.
- Front Cover: 3.2mm Tempered Glass.
- Frame Material: Silver Anodized aluminium alloy.
- Junction Box: IP67/1P68. Cable: 4mm2, 900mm.
- Connector: MC4 Compatible.
WARRANTY.
- 10-year product warranty.
- 10 Years 90% of Min. rated output power, and 25 years 80% of Min. rated output power warranty.
